The 1550nm 1.6kW Pulsed Fiber Laser is an eye-safe 1.5 µm band pulsed fiber laser source for LiDAR, mapping and remote-sensing transmitters. It produces 1.4–1.6 kW peak power at 1550 nm with a 2.5–3.5 pulse and an adjustable 100–2000 kHz repetition rate.
Technical reference 1550-LXMC1.6kw. Request the full specification to confirm the optical, electrical and mechanical configuration for your platform.
Used in: LiDAR 3D mapping, infrastructure inspection and distributed temperature sensing.
1550nm 1.6kW Pulsed Fiber Laser is engineered for civil LiDAR, remote sensing, industrial inspection, and scientific measurement systems that require controlled pulsed output. The 1.6kW peak-power class should be evaluated with the intended pulse regime, fiber delivery, thermal path, and host-system electronics.
Technical reference: 1550-LXMC1.6kw. Confirm the final optical, electrical, mechanical, and environmental configuration against the order-specific technical specification before design release.
| Parameter | Local specification value |
|---|---|
| Laser wavelength | 1550 nm |
| Peak power | 1.6 kW |
| Pulse repetition frequency | 100 500 2000 kHz |
| Pulse width | 2.5 3 3.5 ns |
| Average power | 2.1 W |
| Output fiber | FC/APC |
| Supply voltage | 9 12 13 V |
| Dimensions | 50x70x19 mm |
| Operating temperature | -40 75 ℃ |
We recommend confirming the final optical, electrical, mechanical, and environmental configuration against the order-specific technical specification before design release. This keeps the selected LiDAR laser aligned with the host system and its operating conditions.
